OverviewThe Wire Clamp Fixture is the ideal force gauge attachment for repetitive, tensile testing of wire and similar materials.
|
The Wire Clamp Fixture is the ideal force gauge attachment for repetitive, tensile testing of wire and similar materials.
Large lever allows the quick loading and unloading of materials up to approximately 0.2 inch (5 mm). These wire clamps can withstand material tensile strengths up to 112 lb. (50 kg).
Model | FG-M6WCF5U |
---|---|
Max Width | 0.2 inch (5mm) |
Capacity | 112 lb (50 kg) |
Thread | M6 |
$427.50 |
