Minebea SIWRDCP-V10 is a compact industrial scale in which a standard strain gauge weigh cell is used. Speed-up technology makes the Signum uniquely fast, which means Signum bench scales can weigh in half a second. Minebea preconfigured Signum offers exceptional performance features and is a very easy-to-operate bench scale. The SIWRDCP-V10 is extremely rugged and resistant, and perfectly adapts to any ambient conditions in an industrial environment. With Signum, anything is possible: pick and choose your level of applications and different resolutions, and enjoy the benefits of a wide variety of interfaces and options for IP65 protection, use in harsh areas and for many more features. Sartorius Signum is a compact scale built exactly the way you want it – without compromises.

Model	SIWRDCP-V6	SIWRDCP-V7	SIWRDCP-V8	SIWRDCP-V9	SIWRDCP-V10	SIWRDCP-V11	SIWRDCP-V12	SIWRDCP-V13	SIWRDCP-V14	SIWRDCP-V15
Capacity	3 kg	6 kg	15 kg	35 kg	60 kg	6 kg	6 kg	15 kg	35 kg	60 kg
Readability	0.1 g	0.2 g	0.5 g	1.0 g	2.0 g	0.2 g	1.0 g	0.5 g	1.0 g	2.0 g
Repeatability	0.2 g			1 g	2 g	0.2 g			1 g	2 g
Linearity	0.3 g		0.4 g	0.8 g	1.5 g	3 g	0.4 g	0.8 g	1.5 g	3 g
Weighing Modes	Carats,Grains,Milligrams,Pounds,Ounces,Pennyweight,Grams,Troy Ounces,KiloGrams
Weigh Cell	Strain Gauge
Standard Features	Basic Weighing, RS232 interface, Underhook
Indicator/Platform Material	Die-Cast Aluminum - (AISI304) (Stands up to most citrus applications)
Indicator Cable Length	3 meters (coiled in units base)
Operating Temperature	-10°C to 40°C (14°F to 104°F)
External Calibration	Requires 2,000 g Cal. Weight	Requires 5,000 g Cal. Weight		Requires 10,000 g Cal. Weight	Requires 20,000 g Cal. Weight	Requires 5,000 g Cal. Weight
Display Type	Backlit Liquid Crystal Display with 14 Segments
Power	AC Powered Only
Platform Size	12.6" x 9.4"
Dimensions (W x D)	16.4" x 5.2"
Protection Rating	IP65
Functions	Zero, Tare					Zero, Tare, Counting, Checkweighing, Classification, Averaging(animal weighing), Totalizing, Neutral Measurement, % Weighing, Formulation
Level	Weigh Only Level 1					Applications Level 2

Application Levels and Their Capabilities

Level Capabilities	Level 1	Level 2	Level 3
Keypad	6 Keys	14 Keys	17 Keys
Display	14 Segments	14 segments plus application symbols	14 segments plus application symbols
Weighing	Yes	Yes	Yes
Averaging	N/A	Yes	Yes
Reference Scale Connection	N/A	Yes	Yes
Counting	N/A	Yes	Yes
Totalizing	N/A	Yes	Yes
Checkweighing	N/A	Yes	Yes
Product Data Memory	N/A	N/A	Yes
Date/Time	N/A	Option A31	Option A31
SQ min (min sample qty)	Yes	Yes	Yes
ID Codes (4x40 characters)	N/A	N/A	Yes
