| Engineered for Accuracy, Designed for Demanding Applications The new Explorer Plus (EXP Series) offers a premium weighing performance, compliance support and data traceability. The advanced features take the EXP to the next level by optimizing the user experience. This flagship balance is crafted to meet the most demanding requirements of modern scientific research. more ... |
| Laboratory Equipment > Analytical Balances > Tenth of a Gram - 0.1 g | ||||||
|
||||||
OverviewEngineered for Accuracy, Designed for Demanding Applications The new Explorer Plus (EXP Series) offers a premium weighing performance, compliance support and data traceability. The advanced features take the EXP to the next level by optimizing the user experience. This flagship balance is crafted to meet the most demanding requirements of modern scientific research.
|
||||||
Built for Precision, Powered by Innovation The new Explorer (EXR series) offers an intuitive interface, outstanding weighing performance, and an environmentally friendly design. The new generation Explorer establishes a groundbreaking standard for laboratory operations. Vibrant colors, an easy-to-clean glass panel, and chemical resistance ensure a clear and durable interface. Designed for flexibility, and suitable for small lab cabinets or fume hoods Motorized Leveling System with a digital-level bubble, that ensures a smooth and straightforward setup. Safety protection with IR sensor operation for easy sample access and preventing hand injuries. Designed for laboratory efficiency and specifically designed to assist in sample preparation. The semi-micro model pan is made with zinc alloy, the analytical and precision models have pans made with SST316 and the High-Capacity models with SST304.
Semi-Micro Balance (Zinc alloy) Digital High-Speed Load Cell Elevated Digital Load Cell Platform Internal Calibration Systems Anti-Static Draftshield Built-In Ionizer in Draftshield Models Routine Repeatability Test/strong> Enhanced Security and User Management EXR Explorer
Unique Features:
7-Inch Touchscreen Display
Detachable Terminal and Base
Effortless Setup and Monitoring
Intuitive Sample Handling and Reliable Status Indicators
Sample weighing kit includes Centrifuge Tube Holder, Rotary Evaporators Holder, Needle Holder, and Filter Paper Holder
Enhanced Anti-Pinch Automatic Draftshield Door
Half-open design is tailored for powder samples that require a longer time to stabilize with airflowStandard Square Weighing Pan
Analytical Balance (SST316)
Precision Balance (SST316)
High-Capacity Balance (SST304)
Sample Libraries Shared among Applications
Apply to 15 weighing applications for Explorer Plus EXP and 11 for Explorer EXR. The large sample profile streamlines the workflow
3000 sample libraries for Explorer Plus EXP and 1000 sample libraries for Explorer EXR
Removable Draftshield
For easy cleaning and long-term care and specific large volume weighing applications
Remove EMC plate
Remove the complete draftshield
The digital weighing components (DWC) offer the advantage of creating self-contained load cell modules. Rapid and precise measurements with this advanced technology ensures weighing processes are both swift and highly accurate.
Equipped with 3 ambient sensors to measure key load cell factors: temperature, humidity, and air pressure. Comprehensive monitoring ensures optimal weighing conditions, enhancing the accuracy and reliability of the measurements.
Automatic, user-triggered, and span calibration options ensure precise measurements.
Reduces static electricity around the balance for consistent results.
Removes the static charge from the sample surface and neutralizes the weighing chamber for a stable environment.
Ensures consistent long-term accuracy and reliability. Ideal for critical applications such as weighing in regulated environments, where meeting strict uncertainty requirements is essential (e.g., pharmacopeia mandates uncertainty . 0.10%).
Optional Fingerprint Login System for secure and personalized access. This accessory ensures that only authorized users can access the system, providing a high level of security and data protection.
User management system offering 4 levels of access with an internal system log capacity of 100,000 entries, enabling the tracking and monitoring of user activities efficiently, ensuring compliance and accountability.
Supports Compliance for Data Traceability
Equipped with multiple USB ports, offering unparalleled flexibility. The direct to Excel feature is designed for users who lack the authorization to install drivers, providing a basic yet highly user-friendly solution for data transfer
HID Connection
Human Interface Device allows connections to computers without the need for drivers.
Easy integration with LIMS and MES systems.
Time Synchronization
Network Time Protocol (NTP) ensures accurate timekeeping.
Electronic Signature
When the Electronic Signature feature is enabled, the User ID will be used in the printout field when the User ID content option is selected.
Direct Data Transfer
Direct export to Excel and saving data to USB in CSV and PDF formats
Label Printing Function
2 preset templates and 10 customizable templates for semi-finished product samples transfer management
System Log
All the changes made on balance setting will keep records in system log file. e.g. every printed data, date/time change, balance setting changes, perform calibration action, user log in/log out, user account create/edit/delete and etc. These system log files can be reviewed and exported as a PDF to a USB flash drive.
| Explorer Plus™ EXP | Explorer™ EXR |
|---|---|
|
2x USB Host Type A 1x USB Device Type B 1x USB Device Type C 1x Ethernet 1x RJ11 for Fingerprint accessory 1x RS-232 1x Optional Bluetooth® / WiFi dongle (through USB Host Type A) |
2x USB Host Type A 1x USB Device Type C 1x Ethernet 1x RS-232 1x Optional Bluetooth® / WiFi dongle (through USB Host Type A) |
| Explorer Plus™ EXP | Explorer™ EXR | |
|---|---|---|
| 7-inch display with glass panel | YES | YES |
| Motorized leveling system | YES | - |
| Detachable terminal and base design | YES | - |
| Enhanced auto-doors with anti-pinch safety protection | YES | - |
| Sample spotlight - models with draftshield | YES | - |
| Fingerprint login (accessory) | YES | - |
| Built-in ionizer - models with draftshield | YES | - |
| 3 ambient sensors (load cell temperature, humidity, air pressure) | YES | - |
| Time synchronization NTP (Network Time Protocol) | YES | YES |
| Label printing function (2 preset templates and 10 customized templates) | YES | YES |
| Draftshield status lights | YES | - |
| Terminal status lights | YES | YES |
| 2 x IR sensors | YES | YES |
| Digital level bubble | YES | YES |
| Standard square weighing pan | YES | YES |
| Full metal housing | YES | YES |
| Removable draftshield | YES | YES |
| Out-of-box packaging design | YES | YES |
| Internal calibration systems | YES | YES |
| Draftshield with anti-static coating | YES | YES |
| Powder sample dosing mode | YES | YES |
| 1~9 grade filter level | YES | YES |
| Digital load cell platform | YES | YES |
| HID (Human Interface Device) connection to a computer without drivers | YES | YES |
| 4-level user management and an internal system log capacity of 100,000 entries | YES | YES |
| Sample libraries shared among applications | YES | YES |
| Basic Weighing, Parts Counting, Check Counting, Percent Weighing, Check Weighing, Dynamic Weighing, Totalization, Formulation, Differential, Density Determination, and Peak Hold | td | YES |
| Process Weighing Applications: Pipette Adjustment, SQC, Fill Weight Variation,and Flow Rate Control | YES | - |
| Model | EXP Explorer Plus | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| EXP6201 31059192 |
EXP8201 31059193 |
EXP10201 31059194 |
EXP24001 31059200 |
EXP35001 31059201 |
EXP65001 31059202 |
|||||
| Capacity x Readability | 6200 x 0.1g | 8200 x 0.1g | 10200 x 0.1g | 24000 x 0.1g | 35000 x 0.1g | 65000 x 0.1g | ||||
| Legal For Trade | - | - | - | EXP24001N 31059203 |
EXP35001N 31059204 |
EXP65001N 31059205 |
||||
| - | - | - | 24000 x 1 g (Non NTEP Mode 24000 x 0.1 g) |
35000 x 1 g (Non NTEP Mode 35000 x 0.1 g) |
65000 x 1 g (Non NTEP Mode 65000 x 0.1 g) |
|||||
| NTEP Legal for Trade CLASS II (EXP12202N ClASS I)- COC #26-076 e = 1 g, d= 0.1 g or 1 g |
||||||||||
| Readability d (g) (EXP….N…model) | 0.01 g or 0.1 g | |||||||||
| Verification Interval, e (EXP…N.. models only) | 0.1 g | |||||||||
| Weighing Units (EXP…N.. model only) | g, ct, oz, ozt, Grain, dwt, lb, kg | |||||||||
| Repeatability (sd.), 0.5% of Full Load Typical | 0.07 g | |||||||||
| Repeatability (sd.), 5% of Full Load to Full Range | 0.1 g | |||||||||
| Linearity Deviation Typical | 0.06 g | |||||||||
| Linearity Deviation | 0.2 g | |||||||||
| Span Calibration Points | 2000g, 3000g, 4000g, 6000g | 2000g, 4000g, 6000g, 8000g | 2500g, 5000g, 7500g, 10000g | 2000g, 3000g, 4000g, 6000g0g | 2000g, 4000g, 6000g, 8000g | 2000g, 4000g, 6000g, 8000g | ||||
| Weighing Units | g, ct, N, oz, ozt, Grain, dwt, mo, msg, tl H, tl S, tl T, tcl, tola, baht, lb, kg, Custom 1, Custom 2 | |||||||||
| Applications | Basic Weighing, Parts Counting, Check Counting, Percent Weighing, Check Weighing, Dynamic Weighing, Totalization, Formulation, Differential, Density Determination, Peak Hold, Pipette Adjustment, SQC, Fill Weight Variation, Flow Rate Control | |||||||||
| Stabilization Time (typical) | < 1 seconds | |||||||||
| Sensitivity Temperature Drift (ppm/oC) | 5 | 3 | 3 | 5 | 3 | 3 | ||||
| Min-Weight (typical)(K=2, U=1%) | 14g | |||||||||
| Min-Weight (typical) (USP, K=2, U=0.10%) | 140 g | |||||||||
| Min-Weight (optimal) (USP, K=2, U=0.10%, SRP.0.41d) | 82 g | |||||||||
| Terminal Display | 7-inch TFT 16.7M Color Touch Screen with Glass Overlay, Detachable Terminal |
|||||||||
| Display Resolution | 800 x 480 Pixels | |||||||||
| Communication | USB Host (Type A) x 2 USB Device (Type B) x 1 USB Device (Type C) x 1 Ethernet (RJ45) x 1 RS232 x 1 Optional Wi-Fi, Bluetooth Dongle |
|||||||||
| Leveling System | Motorized Leveling System with Digital Leveling Bubble | |||||||||
| Power Supply | AC Adapter Input: 100-240 VAC 0.5A 50-60 Hz AC Adapter Output: 12 VDC 1.5A |
|||||||||
| Weighing Pan Size | Trapezoid Pan 7.0 in x 7.9 in (178 mm x 201 mm) | Trapezoid Pan 7.0 in x 7.9 in (178 mm x 201 mm) | ||||||||
| Environmental Sensor (Load Cell) | Temperature Sensor, Relative Humidity Sensor (RH), Air Pressure Sensor Touchless Sensor | |||||||||
| Touchless Sensor | 2 Touchless Sensors on the terminal | |||||||||
| Terminal Status Lights | Standard, 7-color Selectable | |||||||||
| Assembled Dimensions (W x D x H) | 229mm x 408mm x 97mm | 229mm x 408mm x 97mm | ||||||||
| Shipping Dimensions (W x D x H) | 385mm x 590mm x 311mm | 229mm x 408mm x 97mm | ||||||||
| Net Weight | 5.5 kg | 5.5 kg | ||||||||
| Shipping Weight | 7.7 kg | 7.7 kg | ||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
