Mark-10 R03 Tension and Compression Force Sensors
Authorized Dealer
Force measurement sensor for tensile and compressive loads in a wide variety of applications, available in capacities from 0.25 lb to 100 lb. Thread on two sides can accept a variety of hooks and implements, making this sensor particularly well suited for inline tests.

Hooks not Inculded

View Specifications Cart

View Test Stands

Specifications Chart

Mark-10 R03 Tension and Compression Force Sensors

FREE UPS Ground Shipping
(within the 48 continental US States)

Model:

Force measurement sensor for tensile and compressive loads in a wide variety of applications, available in capacities from 0.25 lb to 100 lb. Thread on two sides can accept a variety of hooks and implements, making this sensor particularly well suited for inline tests.

  • Compatible with the 5i and 3i digital indicators
  • Unique Plug & TestTM connector holds all calibration and configuration data
  • Rugged aluminum housing
  • Measures tensile and compressive forces
  • NIST-traceable certificate of calibration included
  • Accuracy: ± 0.15% of full scale ±1 digit + indicatorWeight: 0.4 lbs (0.2 kg)
  • Warranty: 3 years
Model MR03-025 MR03-05 MR03-2 MR03-5 MR03-10 MR03-20 MR03-50 MR03-100

$736.25
buy now

$736.25
buy now

$617.50
buy now

$617.50
buy now

$617.50
buy now

$617.50
buy now

$617.50
buy now

$617.50
buy now
Capacity x Resolution
With Model 3i
lbF 0.25 x 0.0002 0.5 x 0.0005 2 x 0.002 5 x 0.005 10 x 0.01 20 x 0.02 50 x 0.05 100 x 0.1
gF 100 x 0.1 250 x 0.2 - - - - - -
kgF - - 1 x 0.001 2.5 x 0.002 5 x 0.005 10 x 0.01 25 x 0.02 50 x 0.05
N 1 x 0.001 2.5 x 0.002 10 x 0.01 25 x 0.02 50 x 0.05 100 x 0.1 250 x 0.2 500 x 0.5
Capacity x Resolution
With Model 5i
lbF 0.25 x 0.0001 0.5 x 0.0002 2 x 0.001 5 x 0.002 10 x 0.005 20 x 0.01 50 x 0.02 100 x 0.05
ozF 4 x 0.002 8 x 0.005 32 x 0.02 80 x 0.05 160 x 0.1 320 x 0.2 800 x 0.5 1600 x 1
gF 100 x 0.05 250 x 0.1 1000 x 0.5 2500 x 1 5000 x 2 10000 x 5 25000 x 10 50000 x 20
kgF - - 1 x 0.0005 2.5 x 0.001 5 x 0.002 10 x 0.005 25 x 0.01 50 x 0.02
N 1 x 0.0005 2.5 x 0.001 10 x 0.005 25 x 0.01 50 x 0.02 100 x 0.05 250 x 0.1 500 x 0.2
mN 1000 x 0.5 2500 x 1 - - - - - -
