AND Weighing Everest EKi and EWi Series Digital Scales
Legal for Trade
currently in stock
Shipping
Weight: 4 lbs. (estimate shipping
cost)
Other AND
scales
Other Industrial
scales
Other Laboratory
scales
|
For years the AND Weighing EK and EW digital scales have been popular compact balances for a wide variety of applications. Now the new AND Everest Compact digital scales have been designed to carry on their tradition with enhanced capacities and resolutions, and AND EW-i models come with attractive triple ranges of weighing. New electronics, wider selection of capacities & resolutions, and remote-zeroing have been included in a low-profile rugged housing. All feature RS-232C standard and are designed to meet Weights and Measures regulations for various countries. (e.g. NTEP, CE).
- Some models Legal for Trade (EW-1500i, EW-12Ki, EK-600i, EK-1200i, EK-6000i, EK-12Ki)
- Large LCD display (16mm height) with back light – Easy to read even at a wide viewing angle or dark environment
- Control zero, mode selection and data output with standard RS-232C
- Wide selection from 16 different models 30g ~ 12kg
- Triple range weighing for EW-i Models
- 9 built-in weighing units plus counting &
percentage with user priority start-up
- Counting function with Automatic Counting Accuracy Improvement (ACAI)
- Standard comparator function – HI/OK/LO annunciator
- Full Digital Calibration with optional user definable mass setting
- Conformity to GLP with I.D. and serial number outputs
- Auto Power OFF
- Portable-compact size, light weight, rugged body
- Sealed key panel protection against dust and spills
- Low profile and small footprint for minimal space requirement
- Overload protection
- Stainless steel weighing pan
- Security ring to prevent theft
- Easy to install rechargeable Ni-MH battery (optional)
- Optional underhook weighing for EK-4100i / 6100i / 6000i / 12Ki and EW-12Ki
- Leveling feet and level bubble for accurate weighing
EK-i Everest Digital Scales - Specifications
* Better Price In Cart (add to cart to see price)
| Model |
EK-120i |
EK-200i |
EK-300i |
EK-410i |
EK-610i |
- |
EK-600i |
EK-1200i |
EK-2000i |
EK-3000i |
EK-4100i |
EK-6100i |
EK-6100J |
EK-6000i |
EK-12ki |
 |
|
| Price |
 |
|
|
|
|
- |
|
|
|
|
|
|
|
|
|
| Capacity x Readability (g) |
120 x 0.01 |
200 x 0.01 |
300 x 0.01 |
400 x 0.01 |
600 x 0.01 |
600 x 0.01 |
600 x 0.1 |
1200 x 0.1 |
2000 x 0.1 |
3000 x 0.1 |
4000 x 0.1 |
6000 x 0.1 |
6000 x 0.1 |
6000 x 1 |
12000 x 1 |
| Legal for Trade |
- |
- |
- |
- |
- |
YES |
YES |
YES |
- |
- |
- |
- |
YES |
YES |
YES |
| Counting Mode |
Max count |
12000 pcs |
20000 pcs |
30000 pcs |
40000 pcs |
60000 pcs |
60000 pcs |
6000 pcs |
12000 pcs |
20000 pcs |
30000 pcs |
40000 pcs |
60000 pcs |
60000 pcs |
6000 pcs |
12000 pcs |
| Min unit weight |
0.01 g |
0.1 g |
1 g |
| # samples |
5, 10, 25, 50 or 100 pieces |
| Percent Mode |
Min div |
0.1% |
| Min 100% weight |
0.01 g |
0.1 g |
100 g |
| RS-232C |
YES |
NO |
YES |
NO |
YES |
| Weighing Modes |
grams, ounces, troy ounces, carats, pennyweight, mommes, taels, grains |
| Linearity |
±0.01 g |
±0.02 g |
±0.1 g |
±0.2 g |
±1 g |
| Repeatability / Std Dev |
0.01 g |
0.1 g |
1 g |
| Sensitivity Drift |
20ppm / C(10C~30C / 50F~86F) |
| weighing units |
g, oz, lb, ozt, ct, mom, dwt, grain |
| Display Type |
7 segment LCD with back light (character height 16mm) |
| Display Refresh |
10 times/second |
| Pan Size (w x d) |
4.3 in / 110 mm |
5.2 x 6.7 in / 133 x 170mm |
5.2 x 6.7 in / 133 x 170 mm |
Dimensions
(w x d x h) |
7.5 x 8.6 x 2.1 inches (190 x 218 x 55 mm) |
| Operating Temp |
10° to 40° C (41° to 104° F), less than 85% relative humidity (non-condensing) |
| Calibration Mass (default setting) |
120 g |
200 g |
300 g |
400 g |
600 g |
600 g |
600 g |
1200 g |
2000 g |
3000 g |
4000 g |
6000 g |
6000 g |
6000 g |
12 kg |
| Power |
AC adapter or Ni-MH battery pack (option) |
| Standard Accessories |
Manual, AC adapter |
EK-KL Precision Bench Scales - Specifications
| Model |
EK-15KL |
EK-30KL |
|
|
| Price |
|
|
| Capacity x Readability |
15 kg x 0.1 g
33 x 0.0005 lb |
3 kg x 0.1 g
6 x 0.0005 lb |
30 kg x 1 g
66 x 0.0005 lb |
| Min unit weight |
0.1 g |
0.1 g |
1 g |
| Repeatability (standard deviation) |
0.3 g |
0.3 g |
1 g |
| Linearity |
±0.6 g |
±0.6 g |
±1 g |
| Sensitivity drift |
±20 ppm/..C (10 to 30..C/50 to 86..F) |
| Counting Mode |
Min. unit weight |
0.1 g |
| No. of samples |
5, 10, 25, 50 or 100 pieces |
| Percent mode |
Min. % display |
0.1% |
| Min. 100% weight |
10 g |
| Operating temperature |
10 to 40..C/50 to 104..F, 85% RH or less (no condensation) |
| Battery life (on a full charge) |
Approx. 100 hours (at 25..C with backlight off) |
| Weighing pan size |
300 × 210 mm |
| Net weight |
Approx. 4.2 kg |
Approx. 4.9 kg |
| Calibration weight |
15 kg |
30 kg |
| Standard accessories |
AC adapter, Instruction manual |
 |
EW Everest Digital Scales - Specifications
| Legal for Trade |
EW-150i |
EW-1500i |
EW-12ki |
|
|
|
|
| Price |
 |
|
|
| Legal for Trade |
- |
YES |
YES |
| Capacity x Readability (g) |
30 x 0.01 |
60 x 0.02 |
150 x 0.05 |
300 x 0.1 |
600 x 0.2 |
1500 x 0.5 |
3000 x 1 |
6000 x 2 |
12000 x 5 |
| Counting Mode |
Max count |
15000 pcs |
15000 pcs |
12000 pcs |
| Min unit weight |
0.01 g |
0.1 g |
1 g |
| # samples |
5, 10, 25, 50 or 100 pieces |
| Percent Mode |
Min div |
0.1% |
| Min 100% weight |
1 g |
10 g |
100 g |
| Weighing Modes |
grams, decimal pounds decimal ounces, troy ounces, carats, pennyweight, mommes, taels (HK), grains |
| Linearity |
+/- 0.01 g |
+/- 0.02 g |
+/- 0.05 g |
+/- 0.1 g |
+/- 0.2 g |
+/- 0.5 g |
+/- 1 g |
+/- 2 g |
+/- 5 g |
| Repeatability |
0.01 g |
0.02 g |
0.05 g |
0.1 g |
0.2 g |
0.5 g |
1 g |
2 g |
5 g |
| Display Type |
7 segment LCD with backlight (character height 16mm) |
| Display Refresh |
10 times/second |
| Pan Size (w x d) |
4.3 in (110 mm) |
5.2 x 6.7 inches (133 x 170 mm) |
| Dimensions |
7.5 x 8.6 x 2.2 inches (190 x 218 x 53 mm) |
| Operating Temp |
10° to 40° C (41° to 104° F), less than 85% relative humidity (non-condensing) |
| Power |
AC Adapter or optional Ni-MH battery pack |
| Standard Accessories |
Manual, AC adapter |
Options
|
|
|
Carrying Case
CC:106 |
Rechargeable Battery
EKW-09i
For complete portability and use in areas with power problems |
External Display
AD-8920 |
|
