Vibra ALE-Series Legal for Trade Laboratory Balances Vibra Balances
Authorized Dealer
ALE provides three advantages as key value. ALE series is new answer to optimized weighing operation in the laboratory. Legal for Trade and RS232C and USB are installed as standard. Short stabilization time is indispensable for efficient weighing operation.
Vibra AJ-Series Analytical
ALE-223, ALE-323, ALE-623
Vibra AJ-Series ALE-1203
ALE-1502, ALE-2202, ALE-3202, ALE-6202
Legal for Trade
Legal For Trade

View Specifications Chart

call us
Vibra ALE-Series Precision Balances

For a limited time only
Add to Cart to see Lower Price

ALE provides three advantages as key value. ALE series is new answer to optimized weighing operation in the laboratory. Legal for Trade and RS232C and USB are installed as standard. Short stabilization time is indispensable for efficient weighing operation.

Minimize operation time with "Free keys" Three keys on the front can work as "free keys". You can assign short-cut of often used functions on these keys. You don't need to push keys many times and minimize operation time.

Compact housing ALE is the most space-saving precision balance. You can install the balance wherever you want, even in very small laboratory.

Short stabilization time We have considerably reduced stabilization time by improved filtering technology. Short stabilization time is indispensable for efficient weighing operation.

Battery drive ALE can be operated with dry-cell batteries thanks to low power consumption in tuning-fork sensor unit. Battery is useful also as reserve electric power

Software applications Specific gravity measurement, formulation, parts counting, etc... Much applications are available with comfortable operation

Communication with outside devices RS232C and USB are installed as standard to connect to outside devices like PC and printer. Extension RS232C, ethernet and relay contact can be available as additional option.

  • Vibra® Tuning Fork Sensor
  • Reads in g, ct, lb, oz t, GN, dwt, mom, mg, oz
  • Configurable RS232 Interface, Windows® Compatible
  • Checkweighing, %, Animal Weighing, Accumulation, Density, GLP Compliant Formulation, Statistics, Specific Gravity
  • Counting Feature NTEP Approved to 0.01 g for Pharmacy Filling
  • Bar Graph Indicator for Capacity Usage
  • HI-LO-GO Comparative Function
  • Below Balance Weighing with Optional Kit
  • Free Programmable Keys
Model ALE-223
(2-ALE-N223-122)
ALE-223
(2-ALE-N323-122)
ALE-623
(2-ALE-N623-122)
ALE-1502
(2-ALE-1502-122)
ALE-2202
(2-ALE-2202-122)
ALE-3202
(2-ALE-3202-122)
ALE-6202
(2-ALE-6202-122)
Price ViBRA ALE-223 Class II NT
$816.48
ViBRA ALE-323 Class II NT
$826.56
ViBRA ALE-623 Class II NT
$1,068.48
ViBRA ALE-1502 Class II N
$719.46
ViBRA ALE-2202 Class II N
$840.42
ViBRA ALE-3202 Class II N
$885.78
ViBRA ALE-6202 Class II N
$1,092.42
Standard
Capacity x Resolution
220 x 0.001 g 320 x 0.001 g 620 x 0.001 g 1500 x 0.01 g 2200 x 0.01 g 3200 x 0.01 g 6200 x 0.01 g
Legal For Trade NTEP COC #17-061
Class II
Legal for Trade
Capacity x Resolution
220 x 0.01 g 320 x 0.01 g 620 x 0.01 g 1500 x 0.1 g 2200 x 0.1 g 3200 x 0.1 g 6200 x 0.1 g
Calibration External calibration
Repeatability (Std. Dev.) ± 0.001 g ± 0.01 g
Linearity ± 0.001 g ± 0.01 g
Stabilization Time < 1.6 seconds < 1.6 seconds
Weighing Units g, ct, lb, oz t, GN, dwt, mom, mg, oz
Functions Specific Gravity, Parts Counting (NTEP for pill counting only), %, Density, Checkweighing (limit function), Animal Weighing, GLP Compliant Formulation, Statistics, Accumulation, Below Balance Weighing
Tare Range To capacity by 100% subtraction
Power Source Input: AC/DC Adapter, 100 - 240 VAC, 50 - 60 Hz, Output: 6 VDC, Dry Cell Batteries (4 x AA, Not Included)
Construction Die cast aluminum base, ABS housing, Stainless Steel Platter, Anti-Static Glass Draft Shield Die cast aluminum base, ABS housing, Stainless Steel Platter
Display Large, easy to read 5/8" (16 mm) LCD display with backlight and icons
Pan Size 118 mm, 4.65" diameter 180 x 180 mm, 7” x 7”
Draft Shield Internal Dimensions (W x D x H) 5.9 x 5.9 x 7.87 inches
150 x 150 x 200 mm
-
Overall Dimensions (W x D x H) 7 x 9 x 3 inches
180 x 230 x 75 mm
(Not including draft shield)
7 x 9 x 3 inches
180 x 230 x 75 mm
Operating Environment 41 °F to 95 °F / 5 °C to 35 °C
Temperature fluctuation < 2°C / hour
Humidity 50% to 85% RH
Connectivity Output RS232 interface, USB Type B, with free RTS data collection software for Windows®
Net Weight 2.86 lb / 1.3 kg
Shipping Weight 6.5 lb / 2.94 kg
Options (Call/email) Ethernet or Relay Contact (only one option per unit), Specific Gravity Measurement Kit, Underweighing Hook


Features Benefits
Easy calibration Calibration is simple, ensuring that the balance will be calibrated often during use
Dedicated print button (output) Easy data transfer to printer or computer
Large stainless steel pan Allows for easy weighing of large objects
Spill ring Protects against damage to electronic components
Adjustable bright, backlit LCD display Easy to read in all lighting conditions including bright sunlight
Multiple weighing units Allows flexibility of weighing
In use dust cover Protects balance against spillage and contamination
4 Leveling feet for adjustment The balance remains level for accurate results even on uneven working surfaces
Configurable RS232 interface and USB Allows communication with peripheral data collection and printing instruments
Free Keys Allows often used applications to be “one key” accessible
Dry Cell Battery Power Allows for portability
