Brecknell MS-1000 Bariatric/Handrail Scale 1000 x 0.5 lb

This electronic Bariatric Handrail scale was designed for either walking on or being wheeled on to be weighed. The stainless steel handrail provides support for those that are unsteady on their feet. more ...
Scales > Medical Scales > Wheelchair Scales
Brecknell MS-1000 Bariatric/Handrail Scale 1000  x 0.5 lb
Brecknell MS-1000 Bariatric/Handrail Scale 1000 x 0.5 lb

Price: $549.00


In Stock - Ships within 24 hours

View Features

SKU: 816965004805
UPC: 816965004805

Features

This electronic Bariatric Handrail scale was designed for either walking on or being wheeled on to be weighed. The stainless steel handrail provides support for those that are unsteady on their feet.

This electronic Bariatric Handrail scale was designed for either walking on or being wheeled on to be weighed. The stainless steel handrail provides support for those that are unsteady on their feet. The scale provides accurate weight with easy-to-read bright 0.8" LED display for easy visibility, weight hold feature and wall or desk mount bracket included for display. Operates on internal battery or AC adapter (included).

Powder coated rugged steel with smooth top plate surface with four 1000 ohm load cells. Two handles and wheels to easily relocate with adjustable foot pads to work effectively on uneven floors. Built-in ramp ends for recessed floors.

  • Accuracy– Provides consistent accuracy within 0.1% and comes equipped with a simple to operate indicator for fast LED digital readout
  • Capacity- 500 kg (1000 lb)
  • Construction– Powder coated rugged steel with smooth top plate surface and two handles and wheels to easily relocate. Adjustable foot pads to work effectively on uneven floors. Built-in ramp ends for recessed floors.
  • Low Profile– 63.5 mm (2.5") high
  • Easy Assembly– No installation costs or parts that require maintenance. Just place the scale on a hard surface and level by adjusting the foot pads. Connect the power and youre ready to go.
  • RS-232 Output

Specifications

Model MS-1000
Capacity x Readability 1000 x 0.5 lb
500 x 0.2 kg
Overload Capacity Capable of withstanding 150% capacity of weight without damaging the scale
Construction Powder coated rugged steel with smooth top plate surface with four 1000 ohm loadcells
Unit Dimension Weighing platform
800 mm x 800 mm x 46 mm
31.5" x 31.5" x 1.8")
Unit Dimension Total length with ramps
1050 mm x 1050 mm
41.3" x 41.3"
Stainless Steel Guard Rail Dimension 860 mm x 700 mm
33.85" x 27.6
Display 6 digit 20 mm (0.8") LED display
Annunciators On/Off/Zero; Tare; Units; Hold/Print
RS-232 Full Duplex, standard 9 pin straight pass through interface connector (interface cable included)
Keyboard On/Off/Zero, Tare, Units, Hold/Print
Calibration Front panel calibration
Loadcell Excitation Voltage +4.4 VDC (max current 55mA)
Power 120/220VAC @ 60/50Hz, 12 VDC, 500mA, UL, CE & BS approved external US, UK and EU adapter (included)
Rechargeable Internal Battery 6V4AH lead acid battery up to 30 hours of continuous use between charges
Operating Temperature 5º C to 35º C (41º F to 95º F)
Tare 100% subtractive
Auto-off Selectable between 1 to 15 minutes after inactivity
Unit Weight 106 lb
Shipping Weight 185 lb
Packaging Contents Indicator, RS-232, manual, 3 power adpaters, bracket with hardware,Platform, handrail and hardware
