Mark-10 MR01 Tension and Compression Force Sensors	Authorized Dealer
A rugged force measurement sensor for tensile and compressive forces up to 10,000 lb. Durable S-Beam architecture allows for many applications and setups. Solid steel construction ensures many years of use in factory or laboratory environments
Force Measurement >> Mark-10

View Specifications Cart View Test Stands Specifications Chart

Mark-10 MR01 Tension and Compression Force Sensors FREE UPS Ground Shipping (within the 48 continental US States) Model: Select MR01-50 $665.00 MR01-100 $665.00 MR01-200 $665.00 MR01-500 $665.00 MR01-750 $665.00 MR01-1000 $665.00 MR01-1500 $665.00 MR01-2000 $665.00 MR01-5000 $950.00 MR01-10000 $950.00

A rugged force measurement sensor for tensile and compressive forces up to 10,000 lb. Durable S-Beam architecture allows for many applications and setups. Solid steel construction ensures many years of use in factory or laboratory environments

• Compatible with the 5i and 3i digital indicators
• Unique Plug & TestTM connector holds all calibration and configuration data
• Measures tensile and compressive forces
• NIST-traceable certificate of calibration included
• Accuracy: ± 0.15% of full scale ±1 digit + indicator
• Weight: From 1.9 lbs (0.9 kg) to 3 lbs (1.4)
• Warranty: 3 years

Model		MR01-50	MR01-100	MR01-200	MR01-500	MR01-750	MR01-1000	MR01-1500	MR01-2000	MR01-5000	MR01-10000
		$665.00	$665.00	$665.00	$665.00	$665.00	$665.00	$665.00	$665.00	$950.00	$950.00
Capacity x Resolution With Model 3i	lbF	50 x 0.05	100 x 0.1	200 x 0.2	500 x 0.5	750 x 0.5	1000 x 1	1500 x 2	2000 x 2	5000 x 5	10000 x 10
	kgF	25 x 0.02	50 x 0.05	100 x 0.1	250 x 0.2	375 x 0.2	500 x 0.5	750 x 1	1000 x 1	2500 x 2	5000 x 5
	N	250 x 0.2	500 x 0.5	1000 x 1	2500 x 2	3750 x 2	5000 x 5	7500 x 10	10000 x 10	-	-
	kN	-	-	-	-	-	-	-	-	25 x 0.02	50 x 0.05
Capacity x Resolution With Model 5i and 7i	lbF	50 x 0.02	100 x 0.05	200 x 0.1	500 x 0.2	750 x 0.5	1000 x 0.5	1500 x 1	2000 x 1	5000 x 2	10000 x 5
	ozF	800 x 0.5	1600 x 1	3200 x 2	8000 x 5	12000 x 10	16000 x 10	24000 x 20	32000 x 20	-	-
	gF	25000 x 10	50000 x 20	-	-	-	-	-	-	-	-
	kgF	25 x 0.01	50 x 0.02	100 x 0.05	250 x 0.1	375 x 0.2	500 x 0.2	750 x 0.5	1000 x 0.5	2500 x 1	5000 x 2
	N	250 x 0.1	500 x 0.5	1000 x 0.5	2500 x 1	3750 x 2	5000 x 2	7500 x 5	10000 x 5	25000 x 10	50000 x 25
	kN	-	-	1 x 0.0005	2.5 x 0.001	3.75 x 0.002	5 x 0.002	10 x 0.005	7.5 x 0.005	25 x 0.01	50 x 0.02
