Detecto MV1 Med Vue Medical Weight Analyzer Indicator
Authorized Dealer
Detecto's MedVue® medical weight analyzer is utilized on select clinical scales. The MedVue® features a striking blue 3.5-in-wide by 3-in-high backlit LCD display screen with nearly 1-in-high weight digit readouts for easy visibility. The MedVue?s 350-degree swivel mounting bracket allows the display to be tilted and rotated into position wherever it is the most convenient for the medical professional and/or patient to view.
Detecto MV1 Med Vue Medical Weight Analyzer Indicator
Med Vue
Indicator

Price: $579.00
In Stock
btn buy

Related Scales


GP-600-MV1 Portable Scale
More Info


6550 Wheelchair Scale
More Info


FHD Wheelchair Scales
More Info


BRW1000 Wheelchair Scale
More Info


7550 Wheelchair Scale
More Info


6500 Wheelchair Scale
More Info


6495 Wheelchair Scale
More Info


6857DHR Bariatric Scale
More Info


6854DHR Bariatric Scale
More Info

View Specifications Chart

Detecto Med Vue Indicator

Price $579.00




Detecto MVIP Wired Ethernet option card for Detecto MV1 , add $239.00

Detecto MVWIFI Wireless Ethernet option card for Detecto MV1 , add $239.00

Detecto Model WACONNECT Welch Allyn Device, add $170.00

Detecto DHRWMStandalone Wall Mount Digital Height Rod, add $235.00

Detecto P50 Direct Thermal Printer With Serial Interface, add $399.00

Detecto P600 Ticket Printer With Serial Interface, add $529.00

Detecto P-150 Mobile Tape Printer With Serial Interface, add $705.00

Detecto MV1PWR AC Adapter for Detecto MV1 , add $59.95


Detecto's MedVue® medical weight analyzer is utilized on select clinical scales. The MedVue® features a striking blue 3.5-in-wide by 3-in-high backlit LCD display screen with nearly 1-in-high weight digit readouts for easy visibility. The MedVue?s 350-degree swivel mounting bracket allows the display to be tilted and rotated into position wherever it is the most convenient for the medical professional and/or patient to view. A host of other benefits include 14-digit patient ID which may be entered via the alphanumeric keypad, 99 stored tare weights, 200 stored transactions, 1LOOK display, and four different languages available in set-up (English, Spanish, French, and German). The MedVue® offers a host of both wired and optional wireless connectivity for sending measurement data to

Versatile Connectivity - DETECTO's MedVue medical weight analyzer offers a host of different options, both wired and optional wireless, for DETECTO scales to connect with multiple devices for efficient EMR/EHR. Connect with:

  • Printers
  • PCs
  • Networks
  • Tablets
  • Bar Code Scanners
  • Even Mobile Phones

BENEFITS OF WI-FI CONNECTIVITY - DETECTOs MedVue offers optional Wi-Fi connectivity with up to 20 ft. range (varies depending upon environmental conditions). Wi-Fi offers a number of benefits over Bluetooth, including greater range and security.


Almost every MedVue port may be used simultaneously (with the exception of Ethernet and Wi-Fi connections). For instance, a printer could be connected to the serial port, PC connected to the USB port, while a tablet is connected via Wi-Fi all at the same time. DETECTOs model P50 printer offers plug-and-play compatibility with the MedVue

350-Degree Swivel Mounting Bracket (Not Included) - Enjoy freedom of movement wherever you need to position the display with the MedVues 350-degree tilt-and-swivel mounting bracket.

EASY SET-UP NAVIGATION - DETECTOs MedVue indicator features a tiered menu system with up/down navigation controls to quickly update any settings you wish to change, such as converting to kilograms-only weighing or lowering the backlight intensity to make the batteries last longer

MULTIPLE LANGUAGE SETTINGS - DETECTOs MedVue features user-prompting in four different languages:

  • English
  • Spanish
  • French
  • German

  • 14-Digit Patient ID
  • 350-Degree Swivel Mounting Bracket (not included)
  • 6 AA Batteries (not included)
  • 99 Stored Tare Weights
  • BMI Calculation
  • EMR/EHR Ready
  • Nearly 1-in-High Weight Readouts
  • NTEP Legal for Trade
  • RS232 Serial and USB Ports Standard
  • Sturdy Steel Construction
  • Wi-Fi and Ethernet Optional
model MV1
Detecto MV1 Med Vue Medic
$579.00
buy now
STANDARD FEATURES
  • Metric Conversion
  • Auto Shut-Off
  • Selectable Sleep-Mode
  • Selectable Filtering
  • 99 Tare Storage
  • Serial I/O (Input/Output)
  • USB Device Port
  • Height Rod Port (for Optional Detecto Digital Height Rod)
  • 200 Transactions Stored
Power Requirements 6 ?AA? cell Alkaline, Ni-Cad or NiMH batteries (not included) OR an optional 12 VDC 1.25A wall plug-in AC power adapter (Detecto part number MV1PWR)
Display Overall Display Size: 3.5 inch W x 3 inch H (89 mm W x 76 mm H) backlit blue LCD
Weight: 5 digit, seven segment, 7/8 inch (22.23 mm) high LCD
Height: 4 digit, seven segment, 1/2 inch (12.7 mm) high LCD
BMI: 3 digit, seven segment, 1/2 inch (12.7 mm) high LCD
ID: 14 digit, 14 segment, 0.35 inch (8.89 mm) high LCD
Sensitivity 0.5 uV/division (0 to 3.0 mV/V), Class III
Operating Temperature 14 to 104 ºF (-10 to +40 ºC)
Signal Input Range 0 to 15mV max.
Transducer Excitation 5.0 VDC
Number of Load Cells up to 4 each 350 Ù
Load Cell Cable Length 30 feet (9 meters) max.
Capacities Weight: 10,000 divisions commercial
Height: 0 - 9 11.9"
BMI: up to 999
Resolution 10,000 divisions
Legal For Trade NTEP Certificate of Conformance Number #13-011
Measurement Canada #AM-5896
Division Value 1, 2 or 5 x 1, 0.1, 0.01, 0.001
Sample Rate 1 to 100 samples per second selectable
Auto Zero Range 0.5 or 1 through 9 divisions
Weighing Units Pounds (lb), Pounds/Kilograms (lb/kg), Kilograms (kg) and Kilograms/Pounds (kg/lb)
Keyboard Membrane type with 19 keys
Enclosure Size 6.75 inch H x 7.63 inch W x 1.75 inch D (171.45 mm W x 193.80 mm H x 44.45 mm D)
Construction Painted steel
OPTIONAL FEATURES
  • MVIP Ethernet Option
  • MVWIFI Wireless Option
  • Detecto DHR (Digital Height Rod)
  • MV1PWR, 12VDC AC Power Adapter
  • Welch Allyn® WACONNECT
  • 350-Degree Swivel Mounting Bracket
