Chatillon LG Series Economical Force Gauges

Chatillon LG  Series Chatillon Force Gauge

Specifications Chart

Over 99% of items IN STOCK for Immediate Delivery! Lowest prices GUARANTEED!

  • Accuracy: +/-0.5% of Full Scale
  • Display: 2-1/4" (57 mm)
  • Peak Capture: Switch selectable
  • Overload Capacity: 110% of capacity
  • Gauge Weight: 1.5 lbs
  • Warranty: 2 years

The Chatillon LG series mechanical force gauge is ideal for a wide range of force testing applications. Based on the popular DPP series force gauge, the LG series push pull gauges feature a larger, 2.25" dial for improved resolution and readability, peak hold function, ergonomic shape, and improved accuracy of +/-0.5% of full scale. The LG series force gauges are an excellent, economical solution for tensile or compression testing.

Chatillon LG series force gauges feature durable, plastic housing that fits naturally in the hand for a comfortable and firm grip even at maximum loads. Gauges can be mounted to a test stand for ever greater control and consistent results in repetitive testing applications. Easy to read concentric dial measures clockwise only. Dial rotates 360 degrees for taring. A peak hold button captures peak readings and can be easily and quickly returned to zero. A mechanical overload feature protects the gauge from damage. Available in lbs, kgs or N units of measure.

LG series force gauges come complete with a protective carrying case and a set of stainless steel attachments. A Certificate of Calibration with Data is supplied standard.

Features:

  • Easy to use, durable construction
  • Tensile or compression testing
  • Intrinsically safe
  • Capacities up to 100 lbs
  • Push or Pull Operations
  • Tare Ring
  • Peak capture
  • NIST calibration with data
  • Standard Accessories: Stainless steel accessories are included for performing a wide variety of measurements, plus a cushioned carrying case.
  • Optional Accessories: Optional gripping fixtures add flexibility to specialized testing needs. Please click here for the Chatillon line of gripping fixtures.
  • Test Stand Usage: The LG gauge is adaptable to most Chatillon test stands for greater control of repetitive testing. Please
  • Click here for recommended Test Stand configurations


Chatillon LG Series Force Gauges
FREE UPS Next Day Air Shipping

currently in stock
Shipping Weight: 5 lbs. (estimate shipping cost)

Other Force Testing Equipment
Other Chatillon Ametek gauges



Optional Accessories

Handle Assembly (NC002753), Add $113.40
MT Series Adapter For LG Series Force Gauges (SPK-MT-0001) , Add $64.00
Test stand adapter for TT Test Stands (NC002582) , Add $103.55

Replacement Parts

Chisel Point Adapter 100 lbf (SPK-FMG-008A), Add $18.00
Point Adapter 100 lbf (SPK-FMG-009A), Add $18.00
Notch Adapter 100 lbf (SPK-FMG-010A), Add $18.00
Flat Adapter 100 lbf (SPK-FMG-011A), Add $18.00
Hook, Stationary 50 lbf (SPK-FMG-012A), Add $18.00
Hook, Stationary 100 lbf (SPK-FMG-012B), Add $26.00
Extension Rod, Low Capacity (#10-32) (SPK-FMG-013A), Add $26.00
LG and MSE100 Series, Carrying Case (Small) (NC002753), Add $69.35


Chatillon LG Series Force Gauges - Specs

Model

Capacity x Graduation - lb

Price

LG-002

2 x 0.01 lb

$739.10

LG-005

5 x 0.025 lb

$739.10

LG-010

10 x 0.05 lb

$739.10

LG-020

20 x 0.1 lb

$739.10

LG-030

30 x 0.15 lb

$739.10

LG-050

50 x 0.25 lb

$739.10

LG-075

75 x 0.375 lb

$739.10

LG-100

100 x 0.5 lb

$739.10
Model Capacity x Graduation - oz Price
LG-080 80 x 4 oz $739.10

Model

Capacity x Graduation - kg

Price

LG-1KG

1 x 0.005 kg

$739.10

LG-2KG

2 x 0.01 kg

$739.10

LG-3KG

3 x 0.015 kg

$739.10

LG-5KG

5 x 0.025 kg

$739.10

LG-10KG

10 x 0.05 kg

$739.10

LG-20KG

20 x 0.1 kg

$739.10

LG-30KG

30 x 0.15 kg

$739.10

LG-50KG

50 x 0.25 kg

$739.10

Model

Capacity x Graduation - N

Price

LG-10N

10 x 0.05 N

$739.10

LG-20N

20 x 0.1 N

$739.10

LG-30N

30 x 0.15 N

$739.10

LG-50N

50 x 0.25N

$739.10

LG-100N

100 x 0.5 N

$739.10

LG-200N

200 x 1 N

$739.10

LG-300N

300 x 1.5 N

$739.10

LG-500N

500 x 2.5 N

$739.10


Included Accessories

Part No. Image Description Capacity
SPK-FMG-012A Hook, Low Capacity 50 lbf 225 N
SPK-FMG-012B Hook, Medium Capacity 100 lbf 500 N
SPK-FMG-008A Chisel Point Adapter 100 lbf (500 N
SPK-FMG-008A Point Adapter 100 lbf (500 N)
SPK-FMG-010A Notch Adapter 100 lbf (500 N)
SPK-FMG-011A Flat Adapter 100 lbf (500 N
SPK-FMG-013A Extension Rod, Low Capacity (#10-32) 100 lbf (500 N
NC002710 DG Series Carrying Case -

Click here for Brochure
(Adobe PDF)
