DI-12 Motorized Torque Tester drives the test piece at consistent speed - Detects breakaway torque without overtorquing pretightened fasteners - Detects the yield torque of the screw joint - Displays real time torque values and captures peak torque - Tightens fasteners to preprogrammed torque values |
 |
DI-12 Motorized Torque Tester drives the test piece at consistent speed and
- Detects breakaway torque without overtorquing pretightened fasteners
- Detects the yield torque of the screw joint
- Displays real time torque values and captures peak torque
- Tightens fasteners to preprogrammed torque values
|
|
- Selectable units: lbf-in, kgf-cm, N-m. ozf-in units avaiable
- Peak, Real Time and Breakaway/Yield measuring modes (selectable)
- RS-232C output
- Both CW and CCW operation
- 1/4" female hex
DI-12-SL Ranges Accuracy: ±1% F.S., 1LSD
| Model |
DI-12-SL4 |
DI-12-SL02 |
DI-12-SL15 |
DI-12-SL4oz |
DI-12-SL02oz |
$3,420.00
|
$3,420.00
|
$4,950.00
|
$3,420.00
|
$3,420.00
|
| Capacity |
lbf-in |
0.30 – 35.00 |
0.015 – 1.800 |
3.0 – 130.0 |
3.0 – 560.0 ozf-in |
0.15 – 28.00 ozf-in |
| kgf-cm |
0.30 – 40.00 |
0.015 – 2.000 |
3.0 – 130.0 |
- |
- |
| N-m (mN-m) |
0.030 - 4.000 N-m |
1.5 - 200.0 mN-m |
0.30 - 15.00 N-m |
- |
- |
| Accuracy |
±1% F.S., 1LSD |
| Display |
4 digit LCD display |
| Operation |
Both CW and CCW motorized rotation |
| Measurement modes |
- P-P: Displays PEAK Torque value that will not change until a higher value is measured.
- T-R: Displays TRANSIENT torque values.
- RG: Determines peak down and yield torque (CW only)
If a peak down torque value is detected, the green indicator will light, and tester rotation will stop automatically. |
| Test Start Value |
Start of RG Mode can be set in 0.001 N-m increments. |
| RS-232 Output |
Continuous (9600 baud) output in PP and RG measuring modes |
| Auto-power-off |
After 5 minutes of non-use |
| Dimensions |
Detector: 44mm diameter × 190mm length, 1/4" hex drive
Indicator: 87mm W × 108mm D × 33mm H |
Dimensions
| |
